China 6FM200（12V200Ah） Suppliers, Manufacturers - Factory Direct Price

Product Description

Dimensions

Terminal

Specifications

Constant Current Discharge Characteristics (A,25℃)
F.V/TIME	10min	15min	30min	60min	90min	2h	3h	5h	8h	10h	20h
9.60V	420	330	200	124	92.0	73.1	51.0	35.7	24.5	20.4	10.69
9.90V	407	322	196	122	91.4	72.6	50.7	35.5	24.3	20.3	10.67
10.2V	391	310	190	119	90.6	72.0	50.4	35.2	24.2	20.3	10.64
10.5V	374	300	185	117	89.2	70.9	50.0	35.0	24.0	20.1	10.57
10.8V	353	284	179	113	88.3	69.1	48.5	34.0	23.3	20.0	10.50
Constant Power Discharge Characteristics (Watt, 25°C)
F.V/TIME	10min	15min	30min	60min	90min	2h	3h	5h	8h	10h	20h
9.60V	4536	3623	2244	1414	1049	846	600	422	291	243	128
9.90V	4400	3536	2199	1392	1042	841	596	419	289	243	128
10.2V	4218	3406	2132	1357	1033	834	592	417	287	242	128
10.5V	4037	3290	2080	1330	1017	821	588	414	285	240	127
10.8V	3810	3116	2004	1289	1007	800	570	401	277	239	126

Note: The above characteristics data can be obtained within three charge/discharge cycles.

Applications

● Alarm and security systems

● Emergency lighting

● Ups and Eps

● Railway signal

● Aircaft signal

● Dc Power Supply

● Solar Power systems .

● Wind Power systems

General Features

Grid refining technology and the thicker plates are used to extend the battery standby life and reduce the plate grid corrosion speed Using oxygen recombination technology: maintenance-free Unique vent valve design:control water losing,prevent air and spark going inside
